| #V-241959 - Vand tuburi VI1-520 (Bi1-520) |
| Tipul anuntului: | Vanzari | |
| Categorie: | TUBURI ELECTRONICE (LAMPI) DE UZ GENERAL SI SOCLURI | |
| Anunt introdus la: | Joi, 6 nov 2025 - 22:07:09 | |
| Autor: | Tase (tase) | |
| Indicativ radio: | ||
| Email: | ||
| Telefon: | 0736171519 | |
| Adresa postala: | ||
| Pret: | IN TEXT | |
| Informatii suplimentare: | ||
| Vand sau schimb cu diverse doua tuburi VI1-5/20 (Bi1-5/20) NOS
(High-vacuum Rectifier.Pulse Rectifier tube) (The VI1-5/20 rectifier tube is designed for use in pulsed-operation circuit) __ OPERATING ENVIRONMENTAL CONDITIONS Vibration loads: frequencies, Hz 10-600 acceleration, m/s2 60 Multiple impacts with acceleration, m/s2 343 Ambient temperature, °C -60 to +70 Relative humidity at up to + 40 °C, % 98 __ BASIC DATA Electrical Parameters Heater voltage, V 6.3 Heater current, A 2.6-3.2 Peak anode current, A, at least 3 Anode current, mA, at least 150 Warm up time, s, at most 55 Cathode-anode capacitance, pF, at most 5 Electrical parameters over 500 h of service: peak anode current, A, at least 2.5 anode current, mA, at least 120 __ Limit Operating Values Heater voltage, V 5.7-6.9 Anode reverse voltage, kV 20 Anode dissipation, W 33 Anode current (peak value), A 5 Anode current (average value), mA Electric charge of pulse, A-µs 50-22 Duration of anode reverse voltage, µs 4 1/duty factor 500 Bulb temperature, °C 300 90lei buc Prefer schimb cu alte tuburi. Pentru detalii puteti suna la nr. de tel. 0736171519 | ||
|
| ||
